Mooer Black Truck Combined Effects Pedal

Mooer Black Truck Combined Effects Pedal Overview :

High Gain
Designed exclusively for the black truck,this analog distortion circuit delivers amp-like distortion with buckets of gain on tap.Perfect for all your hard rock and heavy metal needs
The Mid switch toggles between humped and scooped mids.When combined with the tweak control,which adjusts the shape and feel of the lower frequencies,the effect block becomes incredibly versatile for many different musical applications

MOD
The MOD unit in Black Truck is the same multi-modulation circuit from our popular Red Truck Pedal,Bringing together Phaser,Tremolo,flanger-chorus into a simple and easy to use module

COMP
Based on one of mooers most popular and useful micro pedals,yellow comp is all analog compressor pedal that can provide all means of compression from subtle to transparent squashed and bloomy

OD
A modified Green mile circuit ,the OD module of Black Truck is a warm,and natural analog overdrive circuit with a distinct mid hump

EQ
The Eq module has 5 adjustable frequencies ranging from 100hz-4hz that can be boosted or attenuated +/- 18db as the circuit can be assigned before HI-gain module

Tuner
The tuner in Black truck has been improved to deliver faster response and greater tuning accuracy

DI Output
Following a lot of user feedback on red truck,an independent volume control has been added to the cab simulated output

Features

• 6 effects pedals built into 1 simple unit. Compressor, Overdrive, Distortion, EQ, modulation, Delay/Reverb
• Full-featured controls for each effect
• Built-in precision guitar tuner
• Tap tempo synchronization
• Integrated effects loop for connecting external pedals or 4 cable method connection with an amplifier
• Stereo outputs
• Dedicated direct output with speaker simulation and an independent volume
• control for connection to a mixing desk, computer or headphones
• Includes a carry case for easy transportation

Specifications :

• Input: 1/4" audio jack cable (impedance 2MΩ)
• Output: 1/4" audio jack cable x2 (impedance 100Ω)
• Headphones: 1/8" stereo jack x1 (50Ω)
• Power supply: 9V DC 1A (1000mA)(negative inside positive)
• Size: 370 mm (D) X 96 mm (W) X 51 mm (H)
• Weight: 1.23Kg
• Attachment: Owner’s Manual

Made in China
